Have you ever been frustrated by a sudden machine breakdown?
If your answer is YES, let us introduce you to the
PANDORA REVMA
Power Monitoring Solution
IoT Solution for Real-Time Monitoring
With Pandora Revma, an innovative smart power monitoring IoT solution, you can now monitor your machine's status in real-time to prevent further damage. It offers remote monitoring of the machine's operating status, as well as on/off functions. Additionally, the device measures key metrics such as operating voltage, ampere, power frequency, active power, pF, and energy status, providing you with valuable insights into the health of your machine. These metrics can even be used to calculate OEE, helping you further optimize your operations.
Capabilities
- It measure the machine operating voltage, ampere, power frequency, active power, pF & energy status.
- It able to automatically detect the electric current of the machine, the device provides instant updates to the office on its condition.
- It is made of a corrosion-resistant material, giving it a long service life
- It is equipped with wireless technology, wireless connectivity and is battery powered
Power Monitoring Solution
IoT Solution for Real-Time Monitoring
With Pandora Revma, an innovative smart power monitoring IoT solution, you can now monitor your machine's status in real-time to prevent further damage. It offers remote monitoring of the machine's operating status, as well as on/off functions. Additionally, the device measures key metrics such as operating voltage, ampere, power frequency, active power, pF, and energy status, providing you with valuable insights into the health of your machine. These metrics can even be used to calculate OEE, helping you further optimize your operations.
Capabilities
- It measure the machine operating voltage, ampere, power frequency, active power, pF & energy status.
- It able to automatically detect the electric current of the machine, the device provides instant updates to the office on its condition.
- It is made of a corrosion-resistant material, giving it a long service life
- It is equipped with wireless technology, wireless connectivity and is battery powered
Check out the video to understand our IOT Power monitoring solution
Product Specification
Technical Data
| – Multi wireless network supports (GSM, 4G, EWIFI, Sigfox, Lora, NBIoT) – Support up to 3 – RS485 sensors or control modules |
|
| Display Refresh Time | 10 minutes/30 minutes/1 hour/1 day (customizable) |
Pandora REVMA product sketch
Common Data
Dimensions
Length x Width x Height : 200mm x 155mm x 80mm
Material / Housing
ABS , IP54 Rating
Data Logger
>50,000 measuring values
Software
PANDORA
REVMA Device
| Device Info | |
| Input voltage range | 9-30VDC, reverse polarity protection; surge protection > 31 VDC 10us max |
| Operating temperature | -40°C to 75°C |
| Operating humidity | 10% to 90% non-condensing |
| Current specifications | Single phase – 3 phases |
REVMA Sensor
| Measuring Range | |
| Input Voltage Range | 0-300V AC (Sensor) |
| Voltage Measurement Accuracy | 0.50% |
| Current Measurement Accuracy | 0.50% |
| Power Factor Measurement Accuracy | 1% |
| Power Measurement Accuracy | 1% |
| Active Energy Accuracy | Class 1 |
| Input Voltage | 12 V |
| Response Time | <1s |
